Tsubaki Kabelschlepp · TKA Series
Cable carrier - Tsubaki Kabelschlepp - TKA Series - 38x26mm | R145
TKA038-060-038-145
In stock — ships today
The Tsubaki Kabelschlepp TKA Series is an enclosed plastic cable carrier designed for the reliable protection and guidance of cables and hoses. This model has an inner width of 38 mm and an inner height of 26 mm. Thanks to the design that opens on the inside, cables can be installed and maintained quickly and efficiently.
- Bend radius
- 145 mm
- Pitch
- 42 mm
- Outer height
- 36 mm
- Ordered before 15:00, shipped the same day
- Datasheet and STEP file instantly available
Product description
The Tsubaki Kabelschlepp TKA Series is an enclosed plastic cable carrier designed for the reliable protection and guidance of cables and hoses. This model has an inner width of 38 mm and an inner height of 26 mm. Thanks to the design that opens on the inside, cables can be installed and maintained quickly and efficiently.
This cable carrier has an outer width of 54 mm, an outer height of 36 mm, and a pitch of 38.5 mm. With a bending radius of 145 mm, the product guarantees effective guidance. This item is supplied per meter.
Order directly
Choose a size and quantity. Volume discounts are applied automatically.
TKA038-060-038-145
H 26 × B 38 mm · R 145 mm
1 in stock
€ 84,13per meter · excl. btw
Volume: 10+ € 79,92 (5%) · 15+ € 77,82 (8%) · 20+ € 75,72 (10%)
You also need this
- Secure online payment
- Free shipping from € 250,00
- Technical support
Specifications
| Brand | Tsubaki Kabelschlepp |
|---|---|
| Series | TKA Series |
| Category | Plastic cable carriers |
| Inner height | 26 mm |
| Inner width | 38 mm |
| Outer height | 36 mm |
| Outer width | 54 mm |
| Bend radius | 145 mm |
| Pitch | 42 mm |
| Material | Polyamide PA6 GF |
| Temperature range | −30 °C … +100 °C |
| Max. fill weight | 0.5 kg/m |
| Own weight | 0.2 kg/m |
| Sales unit | meter |
| Origin | Germany |
| Warranty | 24 months |
| Openable | Openable on the inside |
| Design | Closed cable chain |
