Plastic cable carriers
Light, quiet and quick to mount. The standard for machine building, automation and handling.
- Light and quiet in motion
- Open, semi-open and enclosed links
- Quick to fill and mount
- From compact to 120 x 80 mm inner dimension
Cable carriers
Need a cable carrier? Find the right version easily
Cable carriers that guide cables and hoses safely and neatly in moving applications.
Whether you need a cable carrier for a machine, an automation cell, a CNC application or another moving installation: our configurator helps you put together the right version.
Open the cable carrier configuratorRather see all models first? View the full range →
Shipped today
4,200 in stock
Advice within 3 hours
Specialist since 1975
The cable carrier specialist in Europe
Cable carriers guide cables, hoses and lines along a moving axis: from a gantry or CNC machine to a robot cell, crane or conveyor. They keep the cables in place, protect them against kinking and extend their service life.
Steel cable carriers
Robust for heat, chips and long unsupported spans. The choice for cranes, lifting and heavy industry.
- Resistant to heat, chips and heavy loads
- Suitable for long unsupported spans
- Also for outdoor use and harsh conditions
- Robust construction for longer service life
Choose your route
We offer three ways to find the right cable carrier. Pick what fits your situation.
I roughly know what I need
Enter travel, cables and environment and see the matching series, number of links and price straight away.
- Used by 500+ engineers
- Right cable carrier in under 5 minutes
Webshop
I'd rather browse the range first
All series with inner dimensions, bend radii, stock, price and datasheets.
- Ordered today = shipped today
- 4,200 articles in stock
I don't know which one I need
Send us your application with whatever you know; we calculate it and come back with a concrete proposal.
- From the cable carrier specialist in the EU
- Quote within 3 hours
Which cable carrier do I need?
The right choice mainly depends on 4 things:
- 01
Inner dimension
How many cables and hoses have to fit inside?
- 02
Bend radius
How tightly may your cables be bent?
- 03
Travel length
What distance does the cable carrier have to span?
- 04
Application
Where and how is the cable carrier used?
Don't have these details? No problem. Our configurator guides you step by step.
Start the configurator
Prefer direct advice? Send your dimensions or a photo, answer within 3 hours.
Unsure about size or series? Send your photo or dimensions
You get concrete advice from our cable carrier specialist within 3 hours on working days.
- Answer within 3 hours
- Advice from a specialist
- No obligations
Plastic or steel, in numbers
Same question, two materials. The hard limits side by side.
| Plastic | Steel | |
|---|---|---|
| Inner dimension (width) | 10 – 300 mm | 50 – 600 mm |
| Speed | up to 10 m/s | up to 5 m/s |
| Temperature | -40 to +120 °C | -100 to +250 °C |
| Unsupported span | up to approx. 5 m | up to approx. 10 m |
| Weight per metre | low | 3 – 5x higher |
| Noise | quiet | audible |
| Delivery from stock | usually immediate | mostly made to order |
Values are guidelines across the full range; each series has its own limit. We calculate your application.
Three examples from practice
What a typical delivery looks like: industry, application and the series we supplied.
Industry
Machine building
Application
Horizontal gantry axis of 6 metres with 12 cables and two air hoses.
Series supplied
TKA series, inner dimension 75 x 25 mm
Industry
CNC and machining
Application
Short, fast Z axis with daily cycles, oil and coolant.
Series supplied
QuickTrax, quick-opening links
Industry
Cranes and ports
Application
Outdoor installation with a long unsupported span and heavy power cables.
Series supplied
Steel cable carrier, type S/SX
Brands and materials we work with every day
“I sent a photo and the travel length and had a complete proposal with the right inner dimension the same day. That saves us half a day of searching.”
Where our cable carriers are used
Every day at machine builders, integrators and maintenance teams in areas such as:
Machine building
Gantries, handling axes and special machines with daily cycles.
CNC and machining
Enclosed versions against chips, oil and coolant.
Automation and robotics
Fast axes, high cycle counts and short strokes.
Wood and sheet metal
Dusty environments with long horizontal travel.
Cranes and lifting
Long spans, outdoors, with steel versions.
Food and pharma
Easy-to-clean versions with a smooth outer surface.
About Wisman Group
We are a family business from Ruurlo that has done nothing but cable management since 1975. Cable carriers, flexible cables and connecting elements: all from one source.
You speak directly to a technical advisor who has fitted the part himself. We calculate your application, advise on inner dimension, bend radius and mounting, and ship from our own stock.
- Technical expertise
- Online configurator
- Clear product specifications
- Fast delivery
- Large range
- Personal contact
Wisman Group in figures
A family business from Ruurlo that has done nothing but cable management since 1975.
- 50+
- years of experience with cable carriers, since 1975
- 4,200
- articles from our own stock in Ruurlo
- 1,000+
- machine builders and maintenance teams helped
- < 3 hrs
- response time on working days for a technical question
Our cable carriers
Pick the series that suits your application.
Uniflex Advanced Series
Our widest series: many inner dimensions and bend radii, for machine building and handling.
View series
TKA Series
Robust plastic version for heavier fill and longer travel.
View series
QuickTrax Series
Quiet, fast-to-fill series for fast axes and high cycle counts.
View series
EasyTrax Series
Enclosed version that keeps dust, chips and coolant out.
View series
MONO Series
Compact one-piece version for tight mounting space and fine cables.
View series
Steel cable carriers
For heat, chips, outdoor use and long unsupported spans.
View series
Assembled, filled and checked before it leaves our door
We do not just supply links. Your cable carrier can be delivered fully filled, with connecting elements and strain relief, ready to mount.
- Delivered fully filled
- Connecting elements and strain relief included
- Assembled to length
Frequently asked questions about cable carriers
Ask your cable carrier question
Send your question with whatever details you have — we check the application and come back with a concrete proposal, within three working hours.
Live direct contact
Ready to choose your cable carrier?
Choose a route or send your question. You speak directly to an experienced advisor.
- Reply within 3 hours
- Advisor with hands-on assembly experience
- Advice even without a purchase
Tieme ErnstTechnical AdvisorPrefer direct contact?
Call or email us on working days between 08:00 and 17:00. You get an answer to a technical question within three working hours.
